Name: Huawei S6730-H48X6CZ-V2 Best offer and datasheet - fiberolt.com
Brand: Huawei
SKU: 02354VUD
Rating: 5.00 (1 reviews)

Description

S6730-H48X6CZ-V2

48 x 10G SFP+, 6 x 40/100G QSFP28
One extended slot, supports 2 x 100GE, 2 x40GE and 8 x 25/10GE SFP+ cards in the future
All ports support 40GE by default. You can purchase right-to-use (RTU) licenses to upgrade the port rate from 40GE to 100GE

Applicable power module

Dual pluggable power modules, 1+1 power backup
PAC600S12-PB, 600W AC power module
PAC1K2S12-PB, 1200W AC power module
PDC1K2S12-CE, 1200W DC power module

Performance

MAC: 384K
VLAN: 4K
Flash: 2 GB
Memory (RAM): 4GB
Forwarding performance: 490 Mpps
Switching capacity: 2.16Tbps/2.4Tbps

Huawei CloudEngine S6730-H-V2 series switches are next-generation enterprise-class core and aggregation switches that offer high performance, high reliability, cloud management, and intelligent operations and maintenance (O&M). It offers 10GE, 40GE, and 100GE port types, flexibly adapting to diversified network bandwidth requirements. They also support cloud management and implement cloud-managed network services throughout the full lifecycle from planning, deployment, monitoring, experience visibility, and fault rectification, all the way to network optimization, greatly simplifying network management.

Specification

CloudEngine S6730-H48X6CZ-V2 Service Features
Fixed ports	48x 10 Gig SFP+, 6 x 40/100 Gig QSFP28
Dimensions (W x D x H)	442 mm x 420 mm x 43.6 mm
Chassis height(U)	1U
Weight with packaging (kg)	10.46
Weight without packaging (kg)	7.48
Input voltage range	AC input: 90 V AC to 290 V AC; 45–65 Hz High-voltage DC input: 190 V DC to 290 V DC DC input: -38.4 V DC to -72 V DC
Rated input voltage	AC input: 100 V AC to 240 V AC; 50/60 Hz High-voltage DC input: 240 V DC DC input: –48 V DC to –60 V DC
Maximum input current	AC 600W：8A DC 1200W：38A
Typical power consumption (30% of traffic load, tested according to ATIS standard) consumption	234W
Maximum power consumption (100% throughput, full speed of fans)	327 W
User management	Unified user management 802.1X authentication MAC authentication Traffic- and duration-based accounting User authorization based on user groups, domains, and time ranges
MAC	Automatic MAC address learning and aging Up to 384K MAC address entries Static, dynamic, and blackhole MAC address entries Source MAC address filtering MAC address learning limiting based on ports and VLANs
VLAN	4K VLANs Access mode, Trunk mode and Hybrid mode Default VLAN Private VLAN QinQ and enhanced selective QinQ VLAN Stacking Dynamic VLAN assignment based on MAC addresses
ARP	ARP Snooping
DHCP	DHCPv4 Client, DHCPv4 Relay, DHCPv4 Server, DHCPv4 Snooping DHCPv6 Client, DHCPv6 Relay, DHCPv6 Server, DHCPv6 Snooping
IP routing	IPv4 dynamic routing protocols such as RIP v1/v2, OSPF v1/v2, IS-IS, and BGP IPv6 dynamic routing protocols such as RIPng, OSPFv3, ISISv6, and BGP4+ Routing Policy, Policy-Based Routing VRF
Segment Routing	SRv6 BE (L3 EVPN) BGP EVPN SRv6 configuration through NETCONF
Multicast	IGMPv1/v2/v3 and IGMP v1/v2/v3 Snooping PIM-DM, PIM-SM, and PIM-SSM Fast-leave mechanism Multicast traffic control Multicast querier Multicast protocol packet suppression
MPLS	MPLS-LDP MPLS-L3VPN MPLS Qos
VXLAN	Centralized gateway Distributed gateway BGP-EVPN Configures VXLANs through NETCONF
QoS/ACL	Traffic classification based on Layer 2 headers, Layer 3 protocols, Layer 4 protocols, and 802.1p priority Actions such as ACL, Committed Access Rate (CAR), re-marking, and scheduling Queuing algorithms, such as PQ, DRR, WDRR, and PQ+DRR, PQ+WDRR Congestion avoidance mechanisms such as WRED and tail drop Traffic shaping 8 queues on each interface Network Slicing
Native-IP IFIT	Marks the real service packets to obtain real-time count of dropped packets and packet loss ratio The statistical period can be modified Two-way frame delay measurement
Ethernet loop protection	STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s). VLAN-based Spanning Tree (VBST) BPDU protection, root protection, and loop protection G.8032 Ethernet Ring Protection Switching (ERPS)
Security	M-LAG Service interface-based stacking Maximum number of stacked devices Stack bandwidth (Bidirectional) Link Aggregation Control Protocol (LACP) and E-Trunk Virtual Router Redundancy Protocol (VRRP) and Bidirectional Forwarding Detection (BFD) for VRRP BFD for BGP/IS-IS/OSPF/static routes Eth-OAM 802.1ag(CFM) Smartlink LLDP, LLDP-MED
System management	Console terminal service Telnet/IPv6 Telnet terminal service SSH v1.5 SSH v2.0 SNMP v1/v2c/v3 FTP, TFTP, SFTP BootROM upgrade and remote in-service upgrade Hot patch User operation logs Open Programmability System (OPS) Streaming Telemetry
Security and management	NAC RADIUS and HWTACACS authentication for login users MACsec-256 (IEEE 802.1ae) Management by Command Line Interface(CLI) Command line authority control based on user levels, preventing unauthorized users from using command configurations Defense against DoS attacks, Transmission Control Protocol (TCP) SYN Flood attacks, User Datagram Protocol (UDP) Flood attacks, broadcast storms, and heavy traffic attacks IPv6 RA Guard Remote Network Monitoring (RMON) Secure boot Netstream Port mirroring Dynamic ARP Inspection IP Source Guard

Reviews (1)

1 review for S6730-H48X6CZ-V2

Brittany – June 26, 2025

Rated 5 out of 5
The low latency of the Huawei S6730-H48X6CZ-V2 is very noticeable, especially for real-time applications. It’s made a huge difference in our network’s responsiveness.
