S5731-L4P2ST-RUA

S5731-L4P2ST-RUA (4*10/100/1000BASE-T ports, PoE++, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter)

Brand

Huawei
Rate

GE
Quote now
SKU: 98011774 Category:
Description
S5731-L4P2ST-RUA

4*10/100/1000BASE-T ports, PoE++, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter

AC power, power adapter

Performance

Forwarding performance: 11.25 Mpps
Switching capacity: 52 Gbps

Appearance

S5731-L4P2ST-RUA appearance



1-One RST button      2-Four 10/100/1000BASE-T PoE++ ports

3-One 10/100/1000BASE-T port   4-One GE/2.5GE optical port

5-Power adapter socket    6-Ground screw

S5731-L4P2ST-RUA Switch and More Models

S5731-L4P2HW-RUA 4 x 10/100/1000Base-T ports (PoE++), 2 x GE SFP ports (hybrid optical-electrical)

S5731-L4P2S-RUA 4 x 10/100/1000BASE-T ports, PoE++, 1 x GE SFP port, 1 x 10/100/1000BASE-T port

S5731-L4P2HT-RUA 4 x 10/100/1000Base-T ports (PoE++), 1 x GE SFP port(hybrid optical-electrical), 1 x 10/100/1000BASE-T port

S5731-L4T2S-RUA 4 x 10/100/1000Base-T ports, 1 x GE SFP port, 1 x GE port with an SC connector

S5731-L4T2ST-RUA 4 x 10/100/1000Base-T ports, 1 x GE SFP port, 1 x 10/100/1000BASE-T port

S5731-L4P2ST-RUA 4x 10/100/1000Base-T ports (PoE++),1 x GE SFP port, 1 x 10/100/1000BASE-T port

S5731-L8T2ST-RUA 8x 10/100/1000Base-T ports, 1 x GE SFP port, 1*10/100/1000BASE-T port

S5731-L8P2ST-RUA 8x 10/100/1000Base-T ports (PoE+), 1 x GE SFP port, 1 x 10/100/1000BASE-T port

S5731-L8P2HT-RUA 8x 10/100/1000Base-T ports (PoE+), 1 x GE SFP port(hybrid optical-electrical), 1 x 10/100/1000BASE-T port

Specification

Specification

Item Specification
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 38.0 mm x 185.0 mm x 115.0 mm (1.5 in. x 7.28 in. x 4.53 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 38.0 mm x 185.0 mm x 115.0 mm (1.5 in. x 7.28 in. x 4.53 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 82.0 mm x 350.0 mm x 222.0 mm (3.23 in. x 13.78 in. x 8.74 in.)
Chassis height [U] 0.86 U
Chassis material Metal
Weight without packaging [kg(lb)] 1.14 kg (2.51 lb)
Weight with packaging [kg(lb)] 1.46 kg (3.22 lb)
Typical power consumption [W] 6.80 W (device)
7.68 W (device + power adapter)
Typical heat dissipation [BTU/hour] 23.20 (device)
26.21 (device + power adapter)
Maximum power consumption [W] Without PoE: 7.00 W (device)/7.88 W (device + power adapter)
Full PoE load: 88.0 W (PoE: 77 W)
Maximum heat dissipation [BTU/hour] Without PoE: 23.88 (device)/26.89 (device + power adapter)
Full PoE load: 300.27
Static power consumption [W] 4.68 W
Long-term operating temperature [°C(°F)] -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5905.44-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (721.78 ft.).
The device cannot start when the temperature is lower than 0°C (32°F).
The operating temperature of a device ranges from -5°C to +45°C (23°F to 113°F) when the device uses the following optical modules:
– GE optical modules with a transmission distance of less than or equal to 10 km
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Power supply mode Power adapter
Rated input voltage [V] Power adapter input: 100–240 V AC; 50/60 Hz
Power adapter output: 56 V DC
Input voltage range [V] Power adapter input: 90–290 V AC; 47–63 Hz
Maximum input current [A] 1.6 A
Service port surge protection [kV] Common mode: ±6 kV
Power supply surge protection [kV] Power adapter: ±6 kV in differential mode and ±6 kV in common mode
Ingress protection level (dustproof/waterproof) IP20
Heat dissipation mode Natural heat dissipation
PoE Supported
Certification EMC certification
Safety certification
Manufacturing certification
